Vison range of Silica Ramming masses

Vision Range Of Silica Ramming Masses

Quality	Type	Particle Size grinding	Silica Content	Application	Max.Operating Temp.	For Furnace Type
Vison Sil- Ram - 99-B	Acid Ramming Mass	0 - 4 mm	99 %	Dry Ramming	1650⁰ C	Coreless Induction Furnace
Vison Sil- Ram - 99-B	Acid Ramming Mass	0 - 4mm	99 %	Dry Ramming	1650⁰ C	Coreless Induction Furnace
Vison Sil- Ram - 93-B	Acid Ramming Mass With high Refractory Clay	0 - 4mm	99 %	Wet Ramming (6-8 % water to be mixed 24 hours before use)	1650⁰ C	Core type Induction, Channel and Arc Furnace

USEFUL FOR MELTING :
Cast iron/Malleable/S.G.Iron/Mild Steel/Low Alloy Steels/Brass, Copper, etc.

METHOD OF INSTALLATION :

For Only Type Sil-Ram Dry Silica Ramming Masses.

The Ramming Mass is to be pre-heated in a clean tray to a temperature of about 80°C to 90°C for removal of any moisture present.

It is important to ensure that the Ramming Mass is not contaminated with impurities during this reheating operating.

After cooling below 40°C the Ramming Mass is to be mixed uniformly with Boric Acid Binder.

The percentage of Boric Acid will vary between 0.8% to 2.0% depending upon the operating temperature. For cast iron melting furnaces Boric Acid percentage is 1.4 to 1.5 and for steel melting furnace it is 1-1.2%.
